KEYSIGHT - AP5001A-502 - RF Analog Signal Generator 9 kHz - 2 GHz Characterize and stress-test RF devices Whether you’re testing in the lab or on the go, use a quality signal source with the Keysight AP5001A analog signal generator. This product comes in a compact, lightweight size to save space without sacrificing quality, features, or performance. - Cover various radio frequency (RF) applications with accurately leveled output power from -120 dBm to +17 dBm.- Ensure measurement accuracy with OCXO stabilized signal (phase noise -130 dBc/Hz at 1 GHz, 20 kHz offset) with mHz resolution.- Accelerate tests and boost throughput with fast switching speed (down to 20 µs). - Utilize extensive modulation capabilities including AM, FM, PM, pulse modulation, pulse train, and frequency chirps. - Operate smoothly with optimized user interface, including LCD touch screen and remote desktop software. - Be future ready with upgradable licensing options.

KEYSIGHT - AP5001A-504 - RF Analog Signal Generator 9 kHz - 4 GHz Characterize and stress-test RF devices Whether you’re testing in the lab or on the go, use a quality signal source with the Keysight AP5001A analog signal generator. This product comes in a compact, lightweight size to save space without sacrificing quality, features, or performance. - Cover various radio frequency (RF) applications with accurately leveled output power from -120 dBm to +17 dBm.- Ensure measurement accuracy with OCXO stabilized signal (phase noise -130 dBc/Hz at 1 GHz, 20 kHz offset) with mHz resolution.- Accelerate tests and boost throughput with fast switching speed (down to 20 µs). - Utilize extensive modulation capabilities including AM, FM, PM, pulse modulation, pulse train, and frequency chirps. - Operate smoothly with optimized user interface, including LCD touch screen and remote desktop software. - Be future ready with upgradable licensing options.

KEYSIGHT - AP5001A-506 - RF Analog Signal Generator 9 kHz - 6 GHz Characterize and stress-test RF devices Whether you’re testing in the lab or on the go, use a quality signal source with the Keysight AP5001A analog signal generator. This product comes in a compact, lightweight size to save space without sacrificing quality, features, or performance. - Cover various radio frequency (RF) applications with accurately leveled output power from -120 dBm to +17 dBm.- Ensure measurement accuracy with OCXO stabilized signal (phase noise -130 dBc/Hz at 1 GHz, 20 kHz offset) with mHz resolution.- Accelerate tests and boost throughput with fast switching speed (down to 20 µs). - Utilize extensive modulation capabilities including AM, FM, PM, pulse modulation, pulse train, and frequency chirps. - Operate smoothly with optimized user interface, including LCD touch screen and remote desktop software. - Be future ready with upgradable licensing options.

KEYSIGHT - AP5002A-512 - RF Analog Signal Generator 9 kHz - 12 GHz  Characterize and stress-test RF devices Experience the convenience of a compact, powerful testing tool with the Keysight AP5002A analog signal generator as your go-to radio frequency (RF) and microwave signal source.- Use for various RF and microwave applications with accurately leveled output power from -120 dBm to +23 dBm.- Measure accurately with OCXO stabilized signal (phase noise -130 dBc/Hz at 1 GHz, 20 kHz offset) with mHz resolution.- Boost throughput and accelerate testing with fast switching speed.- Leverage a range of extensive modulation capabilities such as AM, FM, PM, pulse modulation, pulse train, and frequency chirps.- Seamlessly operate with an optimized user interface—including an LCD touch screen and remote desktop software. Upgrade licenses at any time for higher frequencies and additional options.

KEYSIGHT - AP5002A-520 - RF Analog Signal Generator 9 kHz - 20 GHz  Characterize and stress-test RF devices Experience the convenience of a compact, powerful testing tool with the Keysight AP5002A analog signal generator as your go-to radio frequency (RF) and microwave signal source.- Use for various RF and microwave applications with accurately leveled output power from -120 dBm to +23 dBm.- Measure accurately with OCXO stabilized signal (phase noise -130 dBc/Hz at 1 GHz, 20 kHz offset) with mHz resolution.- Boost throughput and accelerate testing with fast switching speed.- Leverage a range of extensive modulation capabilities such as AM, FM, PM, pulse modulation, pulse train, and frequency chirps.- Seamlessly operate with an optimized user interface—including an LCD touch screen and remote desktop software. Upgrade licenses at any time for higher frequencies and additional options.

KEYSIGHT - AP5002A-526 - RF Analog Signal Generator 9 kHz - 26 GHz  Characterize and stress-test RF devices Experience the convenience of a compact, powerful testing tool with the Keysight AP5002A analog signal generator as your go-to radio frequency (RF) and microwave signal source.- Use for various RF and microwave applications with accurately leveled output power from -120 dBm to +23 dBm.- Measure accurately with OCXO stabilized signal (phase noise -130 dBc/Hz at 1 GHz, 20 kHz offset) with mHz resolution.- Boost throughput and accelerate testing with fast switching speed.- Leverage a range of extensive modulation capabilities such as AM, FM, PM, pulse modulation, pulse train, and frequency chirps.- Seamlessly operate with an optimized user interface—including an LCD touch screen and remote desktop software. Upgrade licenses at any time for higher frequencies and additional options.

GW INSTEK - GSG-2060 - 6 GHz Vector Signal Generator (GPIB) (CE), AM, FM, PM The GSG-2000 series is a basic RF vector signal/ signal generator that covers a frequency range from 9 kHz to 6 GHz. It is suitable for applications in communications education, RF component testing (such as amplifiers, antennas, and filters), automotive electronic signal testing, and IoT applications. It meets the testing requirements of RF products during production and development stages. Compared to its main competitors, the GSG-2000 series offers superior specifications including a wide amplitude output range of +20 dBm to -140 dBm, lower phase noise of -117 dBc/Hz, and high frequency accuracy with 10 ppm frequency stability and 2 ppm aging rate. Users have the option to enhance frequency stability and aging rate by selecting the OCXO (Oven Controlled Crystal Oscillator) option, which provides 10ppb stability and 0.1 ppm aging rate. For the signal modulation, the entire series has built-in AM, FM, and PM analog modulation, and GSG-2160 features a digital signal modulation function with a maximum bandwidth of 60 MHz digital signal output, supporting ASK, PSK, APSK, QAM, FSK, MSK, User-defined IQ, User-defined FSK modulation signals. Furthermore, the GSG-2000 series also provides LF signal and Pulse signal output. The LF signal allows users to output Sine, Square, Triangle/Ramp, Gaussian Noise signals, and the Pulse signal output can simulate pulse wave applications of various widths. In addition to the above signal outputs, GSG-2000 also provides AM/FM/digital IQ signal input, as well as independent output ports for digital I or Q signals. GSG-2000 adopts a seven-inch TFT LCD display that can fully display the parameters and status set by the user, and the series also provides USB, LAN, GPIB (option) communications interfaces, and provides standard SCPI-compatible commands to support remote control . GSG-2000 is designed for 3U high standard rack size. The GSG-2000 series is available in two models and the main differences are shown in the Datasheet.  Features: - Frequency range: 9 kHz ~ 6 GHz - Frequency resolution: 1 mHz - Standard 10 ppm frequency stability, 2 ppm aging rate - Optional AUX (OCXO): 10 ppb frequency stability, 0.1 ppm aging rate - Amplitude range: -140 dBm to +20 dBm - 0.01 dBm amplitude setting resolution - Amplitude setting unit: dBm, dBµV, Vrms - Phase noise: <-117 dBc/Hz (real) @1 GHz output and 20 kHz offset - The sampling speed of digital modulation signal (I/Q) output reaches 180MSa/s - Frequency/amplitude switching speed: ≤ 5 ms - Built-in LF/RF signal output, Pulse signal output - The series has built-in AM, FM, PM analog signal modulation functions - Supports IQ modulation signal output (GSG-2160 only) - Up to 60 MHz baseband I or Q modulation signal output - Up to 120 MHz RF I+Q modulation signal output - Built-in ASK, PSK, APSK, QAM, FSK, MSK, self-defined IQ/FSK digital signal modulation functions (GSG-2160) - Provides USB, LAN and GPIB (option), commands comply with SCPI standards

GW INSTEK - GSG-2160 - 6 GHz Vector Signal Generator (GPIB) (CE), AM, FM, PM, ASK, PSK, APSK, QAM, FSK, MSK, user define IQ, user defined FSKThe GSG-2000 series is a basic RF vector signal/ signal generator that covers a frequency range from 9 kHz to 6 GHz. It is suitable for applications in communications education, RF component testing (such as amplifiers, antennas, and filters), automotive electronic signal testing, and IoT applications. It meets the testing requirements of RF products during production and development stages.Compared to its main competitors, the GSG-2000 series offers superior specifications including a wide amplitude output range of +20 dBm to -140 dBm, lower phase noise of -117 dBc/Hz, and high frequency accuracy with 10 ppm frequency stability and 2 ppm aging rate. Users have the option to enhance frequency stability and aging rate by selecting the OCXO (Oven Controlled Crystal Oscillator) option, which provides 10ppb stability and 0.1 ppm aging rate.For the signal modulation, the entire series has built-in AM, FM, and PM analog modulation, and GSG-2160 features a digital signal modulation function with a maximum bandwidth of 60 MHz digital signal output, supporting ASK, PSK, APSK, QAM, FSK, MSK, User-defined IQ, User-defined FSK modulation signals.Furthermore, the GSG-2000 series also provides LF signal and Pulse signal output. The LF signal allows users to output Sine, Square, Triangle/Ramp, Gaussian Noise signals, and the Pulse signal output can simulate pulse wave applications of various widths. In addition to the above signal outputs, GSG-2000 also provides AM/FM/digital IQ signal input, as well as independent output ports for digital I or Q signals.GSG-2000 adopts a seven-inch TFT LCD display that can fully display the parameters and status set by the user, and the series also provides USB, LAN, GPIB (option) communications interfaces, and provides standard SCPI-compatible commands to support remote control . GSG-2000 is designed for 3U high standard rack size.The GSG-2000 series is available in two models and the main differences are shown in the Datasheet.Features: - Frequency range: 9 kHz ~ 6 GHz - Frequency resolution: 1 mHz - Standard 10 ppm frequency stability, 2 ppm aging rate- Optional AUX (OCXO): 10 ppb frequency stability, 0.1 ppm aging rate - Amplitude range: -140 dBm to +20 dBm - 0.01 dBm amplitude setting resolution - Amplitude setting unit: dBm, dBµV, Vrms - Phase noise: <-117 dBc/Hz (real) @1 GHz output and 20 kHz offset - The sampling speed of digital modulation signal (I/Q) output reaches 180MSa/s - Frequency/amplitude switching speed: ≤ 5 ms - Built-in LF/RF signal output, Pulse signal output - The series has built-in AM, FM, PM analog signal modulation functions - Supports IQ modulation signal output (GSG-2160 only) - Up to 60 MHz baseband I or Q modulation signal output - Up to 120 MHz RF I+Q modulation signal output - Built-in ASK, PSK, APSK, QAM, FSK, MSK, self-defined IQ/FSK digital signal modulation functions (GSG-2160) - Provides USB, LAN and GPIB (option), commands comply with SCPI standards

KEYSIGHT - HD302MSOOscilloscope, 2 Channels, 200 MHz, 14Bit, 20Mpts/Channel.The HD3 Series brings Keysight’s industry-leading capabilities from high-performance oscilloscopes to the high-volume level, making precision portable from 200 MHz to 1 GHz. Leveraging custom hardware technology from the UXR Series, the HD3 boasts impressive resolution with four times the vertical accuracy with a 14-bit ADC and half the noise floor. Paired with our fast, uncompromised waveform update rate and twenty-five times more memory, the HD3 Series can capture small signals with high vertical resolution.See What You’ve Been Missing with Portable PrecisionMeet the new generation of Keysight InfiniiVision oscilloscopes, the HD3 Series. The HD3 was created with high-performance technology leveraged from our high-speed UXR Series oscilloscopes, now making precision available in a much more portable form factor. With the all-new architecture of the HD3 (including a custom 14-bit ADC and low noise front end), you can analyze all signals in your design with high vertical accuracy. This ensures you make the most accurate measurements possible and have the most realistic view into the signals inside your device. You can achieve even greater accuracy (5x better) with up to 16 bits of resolution using the built-in per channel bandwidth filters. Need to use the full bandwidth to 1 GHz? You will still get extremely high accuracy at the full bandwidth, with the ability to zoom to 500 uV/div.See What You’ve Been Missing with Custom TechnologyThe HD3 Series uses custom components optimized specifically for oscilloscope measurements. Keysight’s R&D team designed a brand-new 14-bit ADC, an all-new ASIC, other support components, and an entirely new architecture for the signal to flow through. Because Keysight designs these components rather than using off-the-shelf components, our hardware works much faster and more efficiently since it is designed specifically for oscilloscopes. Part of this new architecture also includes deep memory with dedicated memory chips for every channel (100 Mpts). This means there is no interleaving between channels. You can have all four channels turned on and still get the maximum memory and sample rate on every channel. Our new custom ASIC (MegaZoom 5) enables the HD3 to have hardware-based functions such as zone trigger, serial decoding, and mask testing. Custom hardware also makes it possible for us to create new custom software, such as the Fault Hunter software application. Simply run Fault Hunter and detect any glitches or errors on your signal.See What You’ve Been Missing with Versatile FunctionalityDive deeper than ever before with more flexibility in the InfiniiVision user interface. Not only did we leverage the hardware from our high-performance oscilloscopes, but we also took some of the more advanced user interface capabilities and added them to the new InfiniiVision user interface. With more menus and user customization, you can set up the scope to be customized to your exact testing requirements. The custom grid display, favorites bar, and automatic actions make it even easier to dive deep into your characterization and view results quickly. All models can be upgraded in bandwidth or memory using immediate license upgrades. There are no returns to factory required for any upgrades. All models are also already equipped with these standard functions that typically cost thousands of dollars:• Frequency response analysis• Fault Hunter• Zone trigger• Segmented memory• MSO• Mask testing• Histograms• FFT, and more

KEYSIGHT - HD304MSO- Oscilloscope, 4 Channels, 200 MHz, 14Bit, 20Mpts/Ch.The HD3 Series brings Keysight’s industry-leading capabilities from high-performance oscilloscopes to the high-volume level, making precision portable from 200 MHz to 1 GHz. Leveraging custom hardware technology from the UXR Series, the HD3 boasts impressive resolution with four times the vertical accuracy with a 14-bit ADC and half the noise floor. Paired with our fast, uncompromised waveform update rate and twenty-five times more memory, the HD3 Series can capture small signals with high vertical resolution.See What You’ve Been Missing with Portable Precision Meet the new generation of Keysight InfiniiVision oscilloscopes, the HD3 Series. The HD3 was created with high-performance technology leveraged from our high-speed UXR Series oscilloscopes, now making precision available in a much more portable form factor. With the all-new architecture of the HD3 (including a custom 14-bit ADC and low noise front end), you can analyze all signals in your design with high vertical accuracy. This ensures you make the most accurate measurements possible and have the most realistic view into the signals inside your device. You can achieve even greater accuracy (5x better) with up to 16 bits of resolution using the built-in perchannel bandwidth filters. Need to use the full bandwidth to 1 GHz? You will still get extremely high accuracy at the full bandwidth, with the ability to zoom to 500 uV/div. See What You’ve Been Missing with Custom Technology The HD3 Series uses custom components optimized specifically for oscilloscope measurements. Keysight’s R&D team designed a brand-new 14-bit ADC, an all-new ASIC, other support components, and an entirely new architecture for the signal to flow through. Because Keysight designs these components rather than using off-the-shelf components, our hardware works much faster and more efficiently since it is designed specifically for oscilloscopes. Part of this new architecture also includes deep memory with dedicated memory chips for every channel (100 Mpts). This means there is no interleaving between channels. You can have all four channels turned on and still get the maximum memory and sample rate on every channel. Our new custom ASIC (MegaZoom 5) enables the HD3 to have hardware-based functions such as zone trigger, serial decoding, and mask testing. Custom hardware also makes it possible for us to create new custom software, such as the Fault Hunter software application. Simply run Fault Hunter and detect any glitches or errors on your signal. See What You’ve Been Missing with Versatile Functionality Dive deeper than ever before with more flexibility in the InfiniiVision user interface. Not only did we leverage the hardware from our high-performance oscilloscopes, but we also took some of the more advanced user interface capabilities and added them to the new InfiniiVision user interface. With more menus and user customization, you can set up the scope to be customized to your exact testing requirements. The custom grid display, favorites bar, and automatic actions make it even easier to dive deep into your characterization and view results quickly. All models can be upgraded in bandwidth or memory using immediate license upgrades. There are no returns to factory required for any upgrades. All models are also already equipped with these standard functions that typically cost thousands of dollars: • Frequency response analysis • Fault Hunter • Zone trigger • Segmented memory • MSO • Mask testing • Histograms • FFT, and more
