MFG-2230M
CHF 513.00
% CHF 570.00 (10% saved)
Product information "MFG-2230M"
GW INSTEK - MFG-2230M
The MFG-2230M is a 30MHz Single Channel Arbitrary Function Generator with Pulse Generator, Modulation
MFG-2230M model outputs have double-channel 30MHz Arbitrary Function Generator and 25MHz pulse generator. The AFG channel of the MFG-2230M outputs sine, square, and triangle, etc. The series features true point by point output arbitrary waveform characteristics of 200MSa/s sample rate, 100MHz waveform repetition rate, 14-bit resolution, and 16k points memory depth.
Features
- Maximum Five Output Channels
- 2 Equivalent Performance Arbitrary Channels Frequency : 1μHz~10/20/30/60/200MHz
- RF Channel Frequency (FG/ARB/MOD) : 160/320MHz
- Pulse Generator Frequency : 25MHz
- Power Amplifier : Low Frequency, 100kHz, Output 20W
- True Point by Point Output Arbitrary Waveform Function: MFG-2220HM Sample Rate: 250MSa/s, Repetition Rate: 125MHz; Other models Sample Rate: 200MSa/s, Repetition Rate: 100MHz, 14-bit Resolution, 16k Points Memory Depth
Earth Ground Isolation Design Among I/O Terminals and Instrument Chassis (MFG-2220HM Excluded)
- Frequency Counter : 150MHz, 8 bits Frequency Resolution
- AM/FM/PM/ASK/FSK/PSK/SUM/PWM Modulation
- Built-in Medical and Automotive Electronic Waveforms(MFG-2220HM Excluded)
- USB Host/USB Device/LAN (MFG-22XX only)
