B2902B
Product information "B2902B"
KEYSIGHT - B2902B
-Dual-channel Precision Source/Measure Unit, 100fA resolution, 210V, 3A DC/10.5A pulse
The Keysight B2902B Precision Source/Measure Units is compact and cost-effective bench-top Source/Measure Units (SMUs) with the capability to source and measure both voltage and current. These capabilities make the B2902B SMU ideal for a wide variety of IV (current versus voltage) measurement tasks that require both high resolution and accuracy.
The B2902B SMU has a voltage maximum of ±210 V, a current maximum ±3 A DC, and ±10.5 A pulsed sourcing capabilities. With a precision minimum of 1 pA/1 uV sourcing and 100 fA/100 nV measuring resolution, a color LCD graphical user interface (GUI) and several task-based viewing modes will improve your productivity for test, debug, and characterization.
The B2902B SMU offers superior measurement throughput and supports conventional SMU SCPI commands for easy test code migration. These features improve efficiency and lower the cost of ownership when integrating the SMUs into systems for production test.
