KEYSIGH - N6762A The Keysight N6762A is a 100 W precision DC power module that provides low noise, and precise control and measurements in the milliampere and microampere region with the ability to simultaneously digitize voltage and current, and capture those measurements in an oscilloscope-like data buffer. For leakage current or sleep-mode current measurements, add option 2UA for measurement capability down to 1 μA.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−500 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 50 V, 3 A, 100 W> Voltage accuracy: 0.016% + 6 mV> Ripple and noise: 4.5 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Basic modules are single wide allowing four per mainframe> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connector

KEYSIGH - N6774A The Keysight N6774A is a 300 W basic DC power module that provides programmable voltage and current, measurement and protection features at a very economical price, making these modules suitable to power the DUT or to provide power for ATE system resources such as fixture control.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−500 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 35 V, 8.5 A, 300 W> Voltage accuracy: 0.1% + 35 mV> Ripple and noise: 22 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Basic modules are single wide allowing four per mainframe> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connector

KEYSIGH - N6781A The Keysight N6781A is a source / measure unit (SMU) designed specifically for the task of battery drain analysis. Whether the device under test (DUT) is an eBook reader, MP3 player, mobile phone, or pacemaker, the N6781A’s seamless measurement ranging, programmable output resistance, and auxiliary DVM combine the best set of advanced features on the market for battery drain analysis. When used with the 14585A Control and Analysis software, the N6781A becomes an even more powerful battery drain analysis solution, offering additional insights into your measurements.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−300 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 20 V, ±1 A or 6 V, ±3 A, 20 W> Voltage accuracy: 0.025% + 1.8 mV> Ripple and noise: 12 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connectorOther features and benefits> Glitch-free sourcing and measurement — change output and measurement ranges without any glitches> Two-quadrant operation — perform as a voltage or current source or as a CV or CC electronic load> Four current measurement ranges — precisely capture the current levels of the DUT during different modes of operation> Excellent transient response — keep voltage or current stable during high-speed load changes> Fast modulation of DC — create waveforms up to 100 kHz to stimulate or load down the DUT> High-speed digitized measurements — capture / view the power consumption of the DUT up to every 5 µs with built-in 200 kHz digitizer

KEYSIGH - N6782A The Keysight N6782A is a source/measure unit (SMU) designed specifically for advanced functional testing of a device. The ability to modulate the output up to 100 kHz along with the capability to source and sink current (2-quadrant operation) makes the N6782A a perfect fit for advanced functional test of a variety of devices such as DC/DC converters, power management units, power amplifiers, and power management ICs. The input stage of the DUT can be stimulated by the fast sourcing and waveform capabilities. While the output stage can be loaded down and measured with the electronic load capabilities, providing a total test solution.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−300 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 20 V, ±1 A or 6 V, ±3 A, 20 W> Voltage accuracy: 0.025 % + 1.8 mV> Ripple and noise: 12 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connectorOther features and benefits> Glitch-free sourcing and measurement ― change output and measurement ranges without any glitches> 2-quadrant operation ― perform as a voltage or current source or as a CV or CC electronic load> Four current measurement ranges ― precisely capture the current levels of the DUT during different modes of operation> Excellent transient response ― keep voltage or current stable during high-speed load changes> Fast modulation of DC ― create waveforms up to 100 kHz to stimulate or load down the DUT> High-speed digitized measurements ― capture/view the power consumption of the DUT up to every 5 µs with built-in 200 kHz digitizer

GW INSTEK - PHU 1000-15D PHU 1000-15D is a 1000 V, 15 A, 5000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 1000-30D PHU 1000-30D is a 1000 V, 30 A, 10000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 1000-45D PHU 1000-45D is a 1000 V, 45 A, 15000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 1500-10D PHU 1500-10D is a 1500 V, 10 A, 5000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 1500-30D PHU 1500-30D is a 1500 V, 30 A, 15000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 200-140D PHU 200-140D is a 200 V, 140 A, 10000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 200-210D PHU 200-210D is a 200 V, 210 A, 15000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 200-70D PHU 200-70D is a 200 V, 70 A, 5000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 500-30D PHU 500-30D is a 500 V, 30 A, 5000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 500-60D PHU 500-60D is a 500 V, 60 A, 10000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 500-90D PHU 500-90D is a 500 V, 90 A, 15000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 750-40D PHU 750-40D is a 750 V, 40 A, 10000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 750-60D PHU 750-60D is a 750 V, 60 A, 15000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 80-170D PHU 80-170D is a 80 V, 170 A, 5000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PHU 80-340D PHU 80-340D is a 80 V, 340 A, 10000 W Programmable DC Power SupplyPrestige / Harmony / UniversalThe PHU Series is a single-channel programmable DC power supply with a autoranging (multi-range) output feature which offers a wide range of voltage and current combinations for greater flexibility. The circuit design adopts SiC (silicon carbide) components to achieve high power density characteristics which can generate 15 kW of high output and keep the compact size at just 3U height.PHU's wide voltage and current range, along with its high-power characteristics, can cover a broader range of testing applications such as photovoltaic systems, electric vehicles (EVs), and automotive electronics, etc. The launch of PHU autoranging (multi-range) high power DC source enhances the completeness of the DC power supply product line of GW Instek, and provides customers with more comprehensive and integrated solutions.The AWS (Advanced Web Server) function allows the user to operate devices directly through a web browser, without needing to install any complicated software or drivers. This functionality allows users to complete tasks more efficiently, saving time and increasing productivity.The unique APC (Adaptive Parallel Connection) feature offers adaptability in parallel connection, allowing users to make the best choice according to their needs. For instance, users can opt for a 15 kW model and a 10 kW model to combine both to reach a 25 kW capacity within their budget constraints. Up to 10 PHU units can be connected to reach 150 kW without the need for additional power distribution for control. For industry interface, PHU provides a variety of embedded industrial interface options to meet user needs, eliminating the need for users to prepare additional interfaces. The available ports including EtherCAT, CANopen, Modbus, Profinet and DeviceNet, etc. Except the standard built-in programmable sequence function, PHU also offers a variety of optional functions including Datalogger, Capacity/Energy, Solar Array Simulator, and Battery Simulation to meet customer’s requirements.There are a total of 18 models, consisting of 3 power capacities (5 kW/10 kW/15 kW) and 6 voltages (80 V/200 V/500 V/750 V/1000 V/1500 V) to meet all customer needs. Features - Voltage output: 80 V/ 200 V/ 500 V/ 750 V/ 1000 V / 1500 V - Power output: 5 kW/ 10 kW/ 15 kW- Maximum current output: 510 A- C.C/ C.V priority mode- Adjustable voltage/current rise and fall time- AWS (Advanced Web Control)- APC (Adaptive Parallel Connection)- Parallel connection (maximum 10 units)- High efficiency and high-power density- Bleeder Control function- Internal Resistance function- Panel lock function- Three sets of Preset Function- Protection: OVP, OCP, OHP, UVL, AC Fail, FAN Fail- Standard: USB, LAN, Isolated Analog control- Option: RS-232&485 or GPIB or CAN Bus or Device Net or Any Bus- 3U height and 19” Rack Mount Size

GW INSTEK - PPX-3601 - 36V, 1A, 36W Programmable High Precision Power SupplyThe PPX series programmable high-precision DC power supplies include six models; PPX- 1005(10V/5A/50W), PPX-2002(20V/2A/40W), PPX-2005(20V/5A/100W) ), PPX- 3601(36V/1A/36W), PPX-3603(36V/3A/108W), and PPX-10H01(100V/1A/100W). This series has the output low noise (0.35mVrms) and fast transient response characteristics (<50μs) of conventional linear power supplies. It also provides constant voltage and constant current priority output modes, and the series can also set the voltage and current rising/falling slew rates separately, and the delay time for the output to be turned on and off.The PPX series has four current levels and two voltage levels to provide users with high-precision measurements, and via the Data Logger function, the measurement records can be stored in the USB for long-term measurement and recording of IoT devices, portable devices, wearable devices, and sensor components.Features:- CV, CC priority start function.- Four levels of current measurement resolution (min. 0.1μA) / two levels of voltage measurement resolution (min. 0.1mV)- Power output ON/OFF delay function- Adjustable voltage and current slew rate- Bleeder circuit control- Delayed over-current protection(OCP Delay)- Sequential power output function- Remote Sensing function- Data Logger- 10 sets of memory function- Over voltage protection, under voltage limit, over current protection, over temperature protection, AC alarm function- Supports K Type thermocouple temperature measurement- Interfaces: USB, LAN, RS-232, RS-485, Analog Control; Opt: GPIB - Size: 3U high, in line with 1/4 Rack

GW INSTEK - PSW 160-14.4 - 160V, 14.4A, 720W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN,USB,Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 160-21.6 - 160V, 21.6, 1080W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN,USB,Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 160-7.2 - 160V, 7.2A, 360W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN, USB, Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 250-13.5 - 250V, 13.5A, 1080W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN, USB, Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver
