ITECH - IT6154 - IT6154 Programmable Linear DC Power Supply 60V / 9A / 540WIT6100 series power supply is designed to meet the test requirements that general supplies can not achieve. High-speed and high-precision features make production line capacity greatly improved, different from the conventional high speed power supply, IT6100 ensures low ripple and noise while meeting the high speed requirements.Key features:- Linear programmable power supply- High-light VFD display- Lower ripple and lower noise- Built-in 5 1/2 digital voltmeter- Support SCPI communication protocol- Optional GPIB/USB/RS232 interfaces- High accuracy and high resolution- PC monitoring software- List mode operation, change output voltage and current quickly- Suitable for 19" standard rack installationConsult the datasheet for a complete list of functions and features.

ITECH - IT8701 - IT8701 Main Frame with GPIB, USB, RS232, Ethernet, 2 slotsThis Main Frame can accomodate up to 2 IT87xx E-Load ModulesIT8700 series programmable DC electronic load adopts removable modules design, with single frame control 8 channels, and 16 channels with extended mainframe extension transient mode up to 25 kHz , which improves your test efficiency, with high resolution and accuracy. Users can freely choose in the 8 load modules according to the number of channels and power requirements, controlled by mainframe control panel, or controlled by IT9000-PV8700 software via built-in LAN / RS232 / USB interface. IT8700, with adjustable slope, list function, automatic test and other functions, automatic test function can be set to work under CC / CV / CR / CP can be used in the application of R&D and production line. IT8700 has self-diagnosis and comprehensive OVP, OCP, OPP, OTP, etc., ensure the operator safety.Key features:- Removable modules for easy system configurability- Dual-channel module can display each channel information simultaneously- Single frame up to max.8 channels, extended frame up to max.16 channels- Dynamic power distribution function for dual channels- Measurement resolution: 0.1mV/0.01mA- Measure short-circuit peak current value and peak voltage value- Measurement speed for voltage, current up to 50kHz- Adjustable current rising / falling slope- Auto-test function, with automatic judgement whether the test result exceeds the set specification- Simulate various waveforms with load under List mode- Up to 25kHz dynamic mode- Automatic test function can automatically determine whether the test results exceed the set specifications- Simultaneously perform multiple sets of electronic load modules- OVP / OCP / OPP / OTP / anti-reverse protection function- Built-in Ether Net / USB / RS232 communication interface • Support anti-reverse alarm function

ITECH - IT8722 - IT8722 DC E-load 2 channels: 2 x 80V / 20A / 250W (Total 300W max.) This E-Load module fits into one slot of a IT8701 or IT8702 Modular E-Load Main Frame. It cannot be used without a Main Frame.IT8700 series programmable DC electronic load adopts removable modules design, with single frame control 8 channels, and 16 channels with extended mainframe extension transient mode up to 25 kHz , which improves your test efficiency, with high resolution and accuracy. Users can freely choose in the 8 load modules according to the number of channels and power requirements, controlled by mainframe control panel, or controlled by IT9000-PV8700 software via built-in LAN / RS232 / USB interface. IT8700, with adjustable slope, list function, automatic test and other functions, automatic test function can be set to work under CC / CV / CR / CP can be used in the application of R&D and production line. IT8700 has self-diagnosis and comprehensive OVP, OCP, OPP, OTP, etc., ensure the operator safety. Key features:- Removable modules for easy system configurability- Dual-channel module can display each channel information simultaneously- Single frame up to max.8 channels, extended frame up to max.16 channels- Dynamic power distribution function for dual channels- Measurement resolution: 0.1mV/0.01mA- Measure short-circuit peak current value and peak voltage value- Measurement speed for voltage, current up to 50kHz - Adjustable current rising / falling slope- Auto-test function, with automatic judgement whether the test result exceeds the set specification- Simulate various waveforms with load under List mode- Up to 25kHz dynamic mode- Automatic test function can automatically determine whether the test results exceed the set specifications- Simultaneously perform multiple sets of electronic load modules- OVP / OCP / OPP / OTP / anti-reverse protection function- Built-in Ether Net / USB / RS232 communication interface- Support anti-reverse alarm function

ITECH - IT8722B - IT8722B DC E-load 2 channels: 2 x 500V / 15A / 150W (Total 300W max.)This E-Load module fits into one slot of a IT8701 or IT8702 Modular E-Load Main Frame.It cannot be used without a Main Frame.IT8700 series programmable DC electronic load adopts removable modules design, with single frame control 8 channels, and 16 channels with extended mainframe extension transient mode up to 25 kHz , which improves your test efficiency, with high resolution and accuracy. Users can freely choose in the 8 load modules according to the number of channels and power requirements, controlled by mainframe control panel, or controlled by IT9000-PV8700 software via built-in LAN / RS232 / USB interface. IT8700, with adjustable slope, list function, automatic test and other functions, automatic test function can be set to work under CC / CV / CR / CP can be used in the application of R&D and production line. IT8700 has self-diagnosis and comprehensive OVP, OCP, OPP, OTP, etc., ensure the operator safety.Key features:- Removable modules for easy system configurability- Dual-channel module can display each channel information simultaneously- Single frame up to max. 8 channels, extended frame up to max.16 channels- Dynamic power distribution function for dual channels- Measurement resolution: 0.1mV/0.01mA- Measure short-circuit peak current value and peak voltage value- Measurement speed for voltage, current up to 50kHz- Adjustable current rising / falling slope- Auto-test function, with automatic judgement whether the test result exceeds the set specification- Simulate various waveforms with load under List mode- Up to 25kHz dynamic mode- Automatic test function can automatically determine whether the test results exceed the set specifications- Simultaneously perform multiple sets of electronic load modules- OVP / OCP / OPP / OTP / anti-reverse protection function- Built-in Ether Net / USB / RS232 communication interface- Support anti-reverse alarm function

ITECH - IT8723 - IT8723 DC E-load 2 channels: 2 x 80V / 45A / 300W (Total 600W max.)This E-Load module fits into one slot of a IT8701 or IT8702 Modular E-Load Main Frame.It cannot be used without a Main Frame.IT8700 series programmable DC electronic load adopts removable modules design, with single frame control 8 channels, and 16 channels with extended mainframe extension transient mode up to 25 kHz , which improves your test efficiency, with high resolution and accuracy. Users can freely choose in the 8 load modules according to the number of channels and power requirements, controlled by mainframe control panel, or controlled by IT9000-PV8700 software via built-in LAN / RS232 / USB interface. IT8700, with adjustable slope, list function, automatic test and other functions, automatic test function can be set to work under CC / CV / CR / CP can be used in the application of R&D and production line. IT8700 has self-diagnosis and comprehensive OVP, OCP, OPP, OTP, etc., ensure the operator safety.Key features:- Removable modules for easy system configurability- Dual-channel module can display each channel information simultaneously- Single frame up to max.8 channels, extended frame up to max.16 channels- Dynamic power distribution function for dual channels- Measurement resolution: 0.1mV/0.01mA- Measure short-circuit peak current value and peak voltage value- Measurement speed for voltage, current up to 50kHz- Adjustable current rising / falling slope- Auto-test function, with automatic judgement whether the test result exceeds the set specification- Simulate various waveforms with load under List mode- Up to 25kHz dynamic mode- Automatic test function can automatically determine whether the test results exceed the set specifications- Simultaneously perform multiple sets of electronic load modules- OVP / OCP / OPP / OTP / anti-reverse protection function- Built-in Ether Net / USB / RS232 communication Interface

ITECH - IT8732- IIT8732 DC E-load 1 channel: 80V / 60A / 400WThis E-Load module fits into one slot of a IT8701 or IT8702 Modular E-Load Main Frame. It cannot be used without a Main Frame IT8700 series programmable DC electronic load adopts removable modules design, with single frame control 8 channels, and 16 channels with extended mainframe extension transient mode up to 25 kHz , which improves your test efficiency, with high resolution and accuracy. Users can freely choose in the 8 load modules according to the number of channels and power requirements, controlled by mainframe control panel, or controlled by IT9000-PV8700 software via built-in LAN / RS232 / USB interface. IT8700, with adjustable slope, list function, automatic test and other functions, automatic test function can be set to work under CC / CV / CR / CP can be used in the application of R&D and production line. IT8700 has self-diagnosis and comprehensive OVP, OCP, OPP, OTP, etc., ensure the operator safety.Key features:- Removable modules for easy system configurability- Dual-channel module can display each channel information simultaneously- Single frame up to max.8 channels, extended frame up to max.16 channels- Dynamic power distribution function for dual channels- Measurement resolution: 0.1mV/0.01mA- Measure short-circuit peak current value and peak voltage value- Measurement speed for voltage, current up to 50kHz- Adjustable current rising / falling slope- Auto-test function, with automatic judgement whether the test result exceeds the set specification- Simulate various waveforms with load under List mode- Up to 25kHz dynamic mode- Automatic test function can automatically determine whether the test results exceed the set specifications- Simultaneously perform multiple sets of electronic load modules- OVP / OCP / OPP / OTP / anti-reverse protection function- Built-in Ether Net / USB / RS232 communication interface- Support anti-reverse alarm function

ITECH - IT8733 - IT8733 DC E-load 1 channel: 80V / 120A / 600WThis E-Load module fits into one slot of a IT8701 or IT8702 Modular E-Load Main Frame. It cannot be used without a Main FrameIT8700 series programmable DC electronic load adopts removable modules design, with single frame control 8 channels, and 16 channels with extended mainframe extension transient mode up to 25 kHz , which improves your test efficiency, with high resolution and accuracy. Users can freely choose in the 8 load modules according to the number of channels and power requirements, controlled by mainframe control panel, or controlled by IT9000-PV8700 software via built-in LAN / RS232 / USB interface. IT8700, with adjustable slope, list function, automatic test and other functions, automatic test function can be set to work under CC / CV / CR / CP can be used in the application of R&D and production line. IT8700 has self-diagnosis and comprehensive OVP, OCP, OPP, OTP, etc., ensure the operator safety.Key features:- Removable modules for easy system configurability- Dual-channel module can display each channel information simultaneously- Single frame up to max.8 channels, extended frame up to max.16 channels- Dynamic power distribution function for dual channels- Measurement resolution: 0.1mV/0.01mA- Measure short-circuit peak current value and peak voltage value- Measurement speed for voltage, current up to 50kHz- Adjustable current rising / falling slope- Auto-test function, with automatic judgement whether the test result exceeds the set specification- Simulate various waveforms with load under List mode- Up to 25kHz dynamic mode- Automatic test function can automatically determine whether the test results exceed the set specifications- Simultaneously perform multiple sets of electronic load modules- OVP / OCP / OPP / OTP / anti-reverse protection function- Built-in Ether Net / USB / RS232 communication interface- Support anti-reverse alarm function

ITECH - IT8733B - IT8733B DC E-load 1 channel: 500V / 30A / 500WThis E-Load module fits into one slot of a IT8701 or IT8702 Modular E-Load Main Frame.It cannot be used without a Main FrameIT8700 series programmable DC electronic load adopts removable modules design, with single frame control 8 channels, and 16 channels with extended mainframe extension transient mode up to 25 kHz , which improves your test efficiency, with high resolution and accuracy. Users can freely choose in the 8 load modules according to the number of channels and power requirements, controlled by mainframe control panel, or controlled by IT9000-PV8700 software via built-in LAN / RS232 / USB interface. IT8700, with adjustable slope, list function, automatic test and other functions, automatic test function can be set to work under CC / CV / CR / CP can be used in the application of R&D and production line. IT8700 has self-diagnosis and comprehensive OVP, OCP, OPP, OTP, etc., ensure the operator safety.Key features:- Removable modules for easy system configurability- Dual-channel module can display each channel information simultaneously- Single frame up to max.8 channels, extended frame up to max. 16 channels- Dynamic power distribution function for dual channels- Measurement resolution: 0.1mV/0.01mA- Measure short-circuit peak current value and peak voltage value- Measurement speed for voltage, current up to 50kHz- Adjustable current rising / falling slope- Auto-test function, with automatic judgement whether the test result exceeds the set specification- Simulate various waveforms with load under List mode- Up to 25kHz dynamic mode- Automatic test function can automatically determine whether the test results exceed the set specifications- Simultaneously perform multiple sets of electronic load modules- OVP / OCP / OPP / OTP / anti-reverse protection function- Built-in Ether Net / USB / RS232 communication interface- Support anti-reverse alarm function

KEYSIGHT - N3304A - Single-slot DC electronic load module, 60 V, 60 A, 300 WThe Keysight N3304A is a 300 W (0−60 A, 0−60 V) electronic load module for use in either the N3300A or N3301A electronic load mainframe in system applications.The N3300 Series supports up to six channels, each with a unique maximum voltage and current. They allow the design of a flexible automated test equipment (ATE) system to verify many types of power supplies, DC-to-DC converters, and batteries. Add additional modules to test multiple power sources simultaneously. Each module includes a 16-bit voltage, current, and power measurement system.Key features:- Choice of half-rack width or full-rack width mainframe- Constant current, constant voltage, and constant resistance modes- Built-in transient generator- 16-bit voltage and current measurements captured simultaneously- Stable operation down to 0 V- Modular design for system flexibility- Fast command processing and settling times- Available interfaces: analog, RS232, and GPIB

KEYSIGHT - N6701CAutomated test equipment (ATE) systems often require more than one power source. The Keysight N6700 Series provides up to four outputs per mainframe. An independent module is the source for each output, allowing for the customization of voltage, current, and performance. DC electronic load modules are also available, allowing testing of power sources in the same 1U high mainframe.Key features:600 W mainframe; Modular solution with 1U low-profile; Up to four outputs per mainframe; Mix and match module power and performance levels; Choose modules from three levels of performance; Sink current with DC electronic load modules; Fast command processing and settling times; Interfaces available — LAN (LXI Core), USB, GPIB.

KEYSIGH - N6752AThe Keysight N6752A is a 100 W high-performance, autoranging DC power module that provides low noise, high accuracy and programming speeds that are up to 10 to 50 times faster than other programmable power supplies. Optional high-speed test extension offers an oscilloscope-like digitizer that increases measurement accuracy when viewing high-speed transient or pulse events within the device-under-test (DUT).This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−500 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 50 V, 10 A, 100 W> Voltage accuracy: 0.06% + 19 mV> Ripple and noise: 4.5 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Basic modules are single wide allowing four per mainframe> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connector

KEYSIGH - N6762A The Keysight N6762A is a 100 W precision DC power module that provides low noise, and precise control and measurements in the milliampere and microampere region with the ability to simultaneously digitize voltage and current, and capture those measurements in an oscilloscope-like data buffer. For leakage current or sleep-mode current measurements, add option 2UA for measurement capability down to 1 μA.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−500 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 50 V, 3 A, 100 W> Voltage accuracy: 0.016% + 6 mV> Ripple and noise: 4.5 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Basic modules are single wide allowing four per mainframe> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connector

KEYSIGH - N6774A The Keysight N6774A is a 300 W basic DC power module that provides programmable voltage and current, measurement and protection features at a very economical price, making these modules suitable to power the DUT or to provide power for ATE system resources such as fixture control.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−500 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 35 V, 8.5 A, 300 W> Voltage accuracy: 0.1% + 35 mV> Ripple and noise: 22 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Basic modules are single wide allowing four per mainframe> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connector

KEYSIGH - N6781A The Keysight N6781A is a source / measure unit (SMU) designed specifically for the task of battery drain analysis. Whether the device under test (DUT) is an eBook reader, MP3 player, mobile phone, or pacemaker, the N6781A’s seamless measurement ranging, programmable output resistance, and auxiliary DVM combine the best set of advanced features on the market for battery drain analysis. When used with the 14585A Control and Analysis software, the N6781A becomes an even more powerful battery drain analysis solution, offering additional insights into your measurements.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−300 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 20 V, ±1 A or 6 V, ±3 A, 20 W> Voltage accuracy: 0.025% + 1.8 mV> Ripple and noise: 12 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connectorOther features and benefits> Glitch-free sourcing and measurement — change output and measurement ranges without any glitches> Two-quadrant operation — perform as a voltage or current source or as a CV or CC electronic load> Four current measurement ranges — precisely capture the current levels of the DUT during different modes of operation> Excellent transient response — keep voltage or current stable during high-speed load changes> Fast modulation of DC — create waveforms up to 100 kHz to stimulate or load down the DUT> High-speed digitized measurements — capture / view the power consumption of the DUT up to every 5 µs with built-in 200 kHz digitizer

KEYSIGH - N6782A The Keysight N6782A is a source/measure unit (SMU) designed specifically for advanced functional testing of a device. The ability to modulate the output up to 100 kHz along with the capability to source and sink current (2-quadrant operation) makes the N6782A a perfect fit for advanced functional test of a variety of devices such as DC/DC converters, power management units, power amplifiers, and power management ICs. The input stage of the DUT can be stimulated by the fast sourcing and waveform capabilities. While the output stage can be loaded down and measured with the electronic load capabilities, providing a total test solution.This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 30 different DC power modules, ranging in capability from basic to high precision, and in power from 20−300 W.Key features> For use with the N6700 Series mainframes (USB, LAN (LXI-C), GPIB): Low profile MPS or DC Power Analyzer> DC output ratings: 20 V, ±1 A or 6 V, ±3 A, 20 W> Voltage accuracy: 0.025 % + 1.8 mV> Ripple and noise: 12 mV> Up and down-programming with resistive load typically 20 ms> Overvoltage, overcurrent, and overtemperature protection> Modules can operate at lower output power to stay within mainframe rating> Modules include a quick disconnect connectorOther features and benefits> Glitch-free sourcing and measurement ― change output and measurement ranges without any glitches> 2-quadrant operation ― perform as a voltage or current source or as a CV or CC electronic load> Four current measurement ranges ― precisely capture the current levels of the DUT during different modes of operation> Excellent transient response ― keep voltage or current stable during high-speed load changes> Fast modulation of DC ― create waveforms up to 100 kHz to stimulate or load down the DUT> High-speed digitized measurements ― capture/view the power consumption of the DUT up to every 5 µs with built-in 200 kHz digitizer

GW INSTEK - PPX-3601 - 36V, 1A, 36W Programmable High Precision Power SupplyThe PPX series programmable high-precision DC power supplies include six models; PPX- 1005(10V/5A/50W), PPX-2002(20V/2A/40W), PPX-2005(20V/5A/100W) ), PPX- 3601(36V/1A/36W), PPX-3603(36V/3A/108W), and PPX-10H01(100V/1A/100W). This series has the output low noise (0.35mVrms) and fast transient response characteristics (<50μs) of conventional linear power supplies. It also provides constant voltage and constant current priority output modes, and the series can also set the voltage and current rising/falling slew rates separately, and the delay time for the output to be turned on and off.The PPX series has four current levels and two voltage levels to provide users with high-precision measurements, and via the Data Logger function, the measurement records can be stored in the USB for long-term measurement and recording of IoT devices, portable devices, wearable devices, and sensor components.Features:- CV, CC priority start function.- Four levels of current measurement resolution (min. 0.1μA) / two levels of voltage measurement resolution (min. 0.1mV)- Power output ON/OFF delay function- Adjustable voltage and current slew rate- Bleeder circuit control- Delayed over-current protection(OCP Delay)- Sequential power output function- Remote Sensing function- Data Logger- 10 sets of memory function- Over voltage protection, under voltage limit, over current protection, over temperature protection, AC alarm function- Supports K Type thermocouple temperature measurement- Interfaces: USB, LAN, RS-232, RS-485, Analog Control; Opt: GPIB - Size: 3U high, in line with 1/4 Rack

GW INSTEK - PSW 160-14.4 - 160V, 14.4A, 720W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN,USB,Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 160-21.6 - 160V, 21.6, 1080W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN,USB,Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 160-7.2 - 160V, 7.2A, 360W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN, USB, Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 250-13.5 - 250V, 13.5A, 1080W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN, USB, Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 250-4.5  - 250V, 4.5A, 360W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN, USB, Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 250-9 - 250V, 9A, 720W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN,USB,Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 30-108 - 30V, 108A, 1080W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN, USB, Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver

GW INSTEK - PSW 30-36 - 30V, 36A, 360W Multi-Range Programmable Switching DC Power Supply  The PSW-Series is a single-output multi-range programmable switching DC Power Supply covering a power range up to 1080W. This series of products include eighteen models with the combination of 30V, 40V, 80V, 160V, 250V, and 800V rated voltages and 360W, 720W and 1080W maximum output powers. The multi-range feature allows the flexible and efficient configuration of voltage and current within the rated power range.As the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW Series significantly reduces the user’s investment for various power supply products to accommodate the projects with different power requirements.The CV/CC priority selection of the PSW-Series is a very useful feature for DUT protection. The conventional power supply normally operates under CV mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under CV mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from CV mode to CC mode.Though the current becomes stable after the CC mode is activated, the current spike occurred at the CV and CC crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to run under CC priority to limit the current spike occurred at the threshold voltage and therefore protect DUT from the inrush current damage. Features:- Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W- Multi-range Voltage & Current Combinations in One Power Supply- CV/CC Priority; Particularly Suitable for the Battery and LED Industry- Adjustable Slew Rate- Series Operation (2 units in Series) for (30V/40V/80V/160V)- Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)- High Efficiency and High Power Density- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W- Standard Interface: LAN,USB,Analog Control Interface- Optional Interface: GPIB-USB Adaptor, RS232-USB Cable- LabView Driver
