Accessories
SENSEPEEK - 6019 - SQ200 - 200 Mhz handsfree oscilloscope probes The ultimate kit that includes everything you need to hold your PCBs during soldering, inspection and handsfree measurements with your multimeter, logic analyzer, oscilloscope or prefered tool. All six included handsfree probes are from the new and improved SQ series.All included probes are insulated and can also be used handheld.This kit contains the 200 MHz bandwidth oscilloscope probes. Other bandwidths are available both as separate probes or in complete kits to match your oscilloscope or measurement needs.The new SQ series of handsfree probes from Sensepeek have a lower point of gravity making them even more stable compared with the original SP series of handsfree probes. All probes in the SQ series are also insulated and can be used handheld as any traditional probe but their full potential is used when measuring handsfree.The SQ series of oscilloscope probes also includes more ground options, have probe tip protection, longer cable and support for oscilloscopes with automatic scaling (10:1)All the loved features of handsfree measurement, exchangeable fine pitch spring tipped test needle, color-coded cable holders and the minimalistic design is maintained to make traditional sized and handheld probes obsolete.Both length and weight of the SQ probes are perfectly balanced to be used with the included PCB holders and base plate which is a must for handsfree function.The probe holder comes with a powerful magnet in the base, as for all PCBite probes and holders which makes the probe easy to place and reposition.One side of the included baseplate is matte and the other is mirror polished. The mirror polished surface makes it easy to see components on the circuit board underside. For added protection during measurement the included insulation cover can be mounted on one of the surfaces.See user guides and included articles (links below) for more details and specifications.Includes:- 2x SQ200 - 200 Mhz handsfree oscilloscope probes (article 6014)- 1x PCBite kit with 4x SQ10 probes and test wires (article 6003)
SENSEPEEK - 4003 - The first truly hands-free probe! Makes instant measurements or long triggering sessions a breeze. No more soldering wires to connect your probe or complicated tools to setup, just positioning the probe needle on any test point or component in the signal path and release. Saves time and frustration during development, verification and repairs. The minimalist design and the spring loaded test needle makes it possible to simultaneously measure on fine pitch components and nearby signals.The probe is steady but yet flexible made for instant measurements or total hands-free operations together with your multimeter, logic analyzer or prefered tool. The dual pin header connector fits directly on a 2.54 mm (0.100") connector. The SP10 comes with a powerful magnet in the base, as for all PCBite probes and holders which makes the probe easy to place and reposition.It includes:- 4× PCBite holder- 1× Large Base plate (A4)- 4× SP10 probes with pin tipped test needles- 4× Extra test needles- 1× Set of yellow insulation washers- 5× Dupont to dupont test wires- 2× Banana to dupont test wires- 1× Micro fiber cloth
RIGOL - PVP3150 - 150 MHz Passive Probe with 1x:10x selector. Wide bandwidth of 20 MHz in 1x mode. 150 MHz Passive Probe with 1x:10x selector. Wide bandwidth of 20 MHz in 1x mode.
SENSEPEEK - PCBITE-7024 - PCBite kit XS insulated low profileThe PCBite kit XS insulated low profile includes four low profile PCB holders that secure your board at a height of just 20 mm, compared to the standard 50 mm. This reduced height is ideal for use in TEM cells, soldering low profile PCBs, and in mixed test setups where different PCB heights are needed.The included extra small base plate comes pre-fitted with an insulation cover and features a mirror surface on the back for added utility. Due to its compact size and light weight, rubber feet are included to provide extra friction and stability during use.INCLUDES:- 4× PCBite holder low profile- 1x XS insulated base plate- 1x Set of yellow insulation washers- 1x Set of rubber feets (6pcs)- 1x Micro fiber cloth
SENSEPEEK - 4007 - Large Base Plate and 4x PCBite holderPerfect for holding your PCB for soldering or inspection. With larger base plate to fit larger PCBs or more room for multiple interconnected PCBs during test.It includes:- 4× PCBite holder- 1× Large Base plate (A4)- 1× Set of yellow insulation washers- 1× Micro fiber cloth
SENSEPEEK - 6011 - SQ10 probes The new SQ series of handsfree PCBite probes from Sensepeek are insulated, come with included color-coded cable holders and have a lower point of gravity making them even more stable compared with the original SP series of probes. All the loved features of handsfree measurement, exchangeable fine pitch spring tipped test needle and the minimalistic design is maintained to make traditional sized and handheld probes obsolete. All handsfree probes from Sensepeek makes instant measurements or long triggering sessions a breeze. The minimalist design and the spring-loaded test needle makes it possible to simultaneously measure on fine pitch components and nearby signals. Both length and weight of the SQ probes are perfectly balanced to be used with PCBite PCB holders and base plate which is a must for handsfree function. The probe holder comes with a powerful magnet in the base, as for all PCBite probes and holders which makes the probe easy to place and reposition. The SQ series of probes can be used handheld without the probe holder as they have an insulated grip but their full potential is used when measuring handsfree.Includes:- 2x SQ10 probes and pin tipped test needles (red/black)- 2x Banana to dupont test wires (red/black)- 1x Set of cable holders (red/black)- 2x Extra test needles
Sensepeek - 6014 - SQ200 - 200 MHz handsfree oscilloscope probeThe new SQ series of handsfree probes from Sensepeek have a lower point of gravity making them even more stable compared with the original SP series of handsfree probes. All probes in the SQ series are also insulated and can be used handheld as any traditional probe but their full potential is used when measuring handsfree. The SQ series of oscilloscope probes also includes more ground options, have probe tip protection, longer cable and support for oscilloscopes with automatic scaling (10:1) All the loved features of handsfree measurement, exchangeable fine pitch spring tipped test needle, color-coded cable holders and the minimalistic design is maintained to make traditional sized and handheld probes obsolete. Both length and weight of the SQ probes are perfectly balanced to be used with PCBite PCB holders and base plate which is a must for handsfree function. See user guide for specifications. Includes: 1x SQ200 200 MHz probe with spring tipped test needle 1x SQ probe holder for handsfree measurement 1x Testhook with detachable cables (5cm & 10cm) for convenient ground connection 1x Alligator cable for convenient ground connection 1x Standard ground spring, for handheld measurements at rated bandwidth 1x Unique ground spring, for total handsfree measurements at rated bandwidth 1x Set of color coded cable holders(4 colors) 1x Probe tip protection 1x Extra test needle
SENSEPEEK - 4005 - 4x SP10 probes with test wiresIt is perfect for holding your PCB for soldering or inspection. With larger base plate to fit larger PCBs or more room for multiple interconnected PCBs during test.
SENSEPEEK - 6012 - The new SQ series of handsfree PCBite probes from Sensepeek are insulated, come with included color-coded cable holders and have a lower point of gravity making them even more stable compared with the original SP series of probes. All the loved features of handsfree measurement, exchangeable fine pitch spring tipped test needle and the minimalistic design is maintained to make traditional sized and handheld probes obsolete.The minimalist design and the spring-loaded test needle makes it possible to simultaneously measure on fine pitch components and nearby signals.Both length and weight of the SQ probes are perfectly balanced to be used with the included PCB holders and base plate which is a must for handsfree function.The probe holder comes with a powerful magnet in the base, as for all PCBite probes and holders which makes the probe easy to place and reposition.The SQ series of probes can be used handheld without the probe holder as they have an insulated grip but their full potential is used when measuring handsfree.One side of the included baseplate is matte and the other is mirror polished. The mirror polished surface makes it easy to see components on the circuit board underside. For added protection during measurement the included insulation cover can be mounted on one of the surfaces.Includes:- 4x PCBite PCB holders- 1x Set of yellow insulation washers for the PCB holders- 1x Large Base plate (A4)- 1x Insulation cover for the base plate (A4)- 1x Micro fiber cloth- 2x SQ10 probes and pin tipped test needles (red/black)- 2x Banana to dupont test wires (red/black)- 1x Set of cable holders (red/black)- 2x Extra test needles
SENSEPEEK - 4017-Insulation CoverThis accessory is the right solution if you are looking for extra protecting when working with powered PCBs, want to clean up your worksurface or eliminate reflection from microscope lightning when working with small PCBs under microscope. The baseplate included in all PCBite kits have one mirror polished surface and one brushed metal surface you can choose freely on what you want to mount the insulation cover on. This insulation covers fits the large baseplate included in all PCBite kits except the PCBite kit with small baseplate (article 4002). It includes: - 1x Insulation cover
SENSEPEEK - 4011 - SP10 probes2 psc complete SP10 probes with one red and one black probe head (positive and negative) packed together with a set of red/black banana cables. Intended for connection directly to multimeter or power supply. These probes are perfect for those who already has a metal base plate and holders which is a must for the function.It includes:- 2× SP10 probes with red/black probe head and pin tipped test needles- 2× Banana to dupont test wires red/black- 2× Extra test needles
SENSEPEEK - 4020 - 3x magnification edgeless lens for increased visibility of the work surface and AR coating (anti-reflection) to reduce reflections from nearby light sources. PCBite Magnifier enlarges your target and makes it easier to see during soldering, inspection and measurements. Especially useful when placing PCBite hands free probes on fine pitch SMD components during measurements. At the bottom of the magnifier foot there is a strong magnet perfectly balanced in strength. A low friction bottom cap protects the magnet and makes the magnifier easy to slide on the PCBite base plate. Friction based adjustment of lens tilt and rotate positions takes away the need for annoying and complicated set screws. Premium build quality made from CNC machined aluminum matching the look and feel of the rest of the PCBite family of products. Optimized design, magnification and focal point for use together with the PCBite PCB holders and baseplates included in all PCBite kits. Can also be used handheld but not standalone without a metal surface as base.Key features:- Lens magnification: 3x- Coating: Anti reflective- Diameter lens: 90 mm- Height: 150 mm
SENSEPEEK - 4021 - Insulation CoverComponents are both shrinking and getting increasingly finer pitch year after year but your PCBs might have grown in size or the number of interconnected PCBs or the number of handsfree PCBite probes needed to test your design may have increased making it crowded on our other smaller base plates. The extra large 297 x 420 mm (DIN A3) base plate comes with a pre-fitted insulation cover so your PCBs are well protected when powered up. The pre fitted insulation cover adds a higher level of protection compared to having a painted metal surface as it is more resistant to wear and and less risk of exposing bare metal over time. Designed to be used with Sensepeeks magnetic PCBite line of products including PCB holders, hands free probes and magnifier.Includes:- 1x XL (297 x 420 mm) base plate (DIN A3) with pre-fitted insulation cover
RIGOL - BAG-800 - Instrument bag for Rigol DHO800/DHO900 oscilloscope series. Instrument bag for Rigol DHO800/DHO900 oscilloscope series.
RIGOL - PLA2216 - Logic Analyzer Probe PLA2216 for MSO5000-Series oscilloscopes. 16 Channels, ground connections. As a high-performance active logic Probe, PLA2216 connects the digital signals under test to the MSO5000 and the DHO900/S series digital oscilloscope to realize the logic analyzer function. No extra License is needed. Insert it into front interface of MSO5000 Oscilloscope, then customer can use it.
KEYSIGHT - N2790AKey features:- User-selectable attenuation settings of 50:1 or 500:1- Rated to measure differential voltage up to 1,400 VDC + peak AC with high CMRR of >50 dB at 1 MHz. - Overrange indicator which alerts the user when the probe input exceeds the dynamic range of the probe- AutoProbe interface Included accessories: - Two browser tips - Two retractable hook tips - Two alligator clips Compatible oscilloscopes: - Keysight InfiniiVision 3000 X-Series, 4000 X-Series - Keysight InfiniiVision 5000, 6000 (except for 100 MHz) and 7000 Series with software V. 5.26.0001 or higher - Keysight Infiniium S-Series - Keysight Infiniium V-Series, Z-Series, 90000 X-Series, and 90000 Q-Series with N5449A adapter - Keysight Infiniium 8000 and 54830 Series with software version 5.7 - Keysight 9000 Series with software version 2.0 Use the N2790A 100-MHz high-voltage differential probe to make safe and accurate floating measurements with an oscilloscope. The N2790A probe allows conventional earth-grounded Keysight oscilloscopes to be used for floating signal measurements of up to 1,400 V of differential voltage and 1,000 V of common mode voltage.Thanks to its high bandwidth and excellent input-impedance characteristics, the probe can accurately measure up to 3.5 nsec of fast transient edges in modern switching power supplies. The probe is compatible with Keysight’s AutoProbe interface with 1 Mohm input where the probe’s power is supplied by the Keysight oscilloscope’s probe interface. When probing differential signals inside of environmental chambers at extreme temperatures, Keysight offers the N7013A extreme temperature extension kit. The N7014A is compatible with the N2790A with a de-rated bandwidth of 70 MHz. The 70 cm long differential cable set and accessories can operate in temperatures ranging from -40 degrees to +85 degree Celsius.
SENSEPEEK - 4002 - Base plate DIN A5 (210x148mm) with four PCBite PCB holders. Perfect for holding your PCB for soldering or inspection. It includes:- 4× PCBite holder- 1× Small Base plate (A5)- 1× Set of yellow insulation washers- 1× Micro fiber cloth
SENSEPEEK - 4008 - Wire Harness - 2x4 Saleae2×4 Wire harness that fits perfectly between PCBite probes and your Saleae logic analyzer or anything else with an IDC 2,54 (0.1") pitch pin header.It includes:- 4 wires intended for ground and 4 for signals.- Color coded to match Saleae software (channels 4−7)- Total length is 0,8 meter (31,5")- Tested with: Saleae Logic 4, Logic 8, Logic Pro 8, Logic Pro 16 (Generation 2)
Keysight - 82357B - USB to GPIB Interface Easily connect to GBIP instruments from a USB port; no switches, no PC cards, and no external power supplies required. Key features: Easy connection — plug-and-play interface USB 2.0 interface (USB 1.1 compatible) and IEEE-488 interface (connect up to 14 GPIB instruments) A wide selection of interfaces to fit your test system application: PCI, PCIe, USB and LAN High-speed — transfer over 1.15 Mb/sec Parallel Polling (check response of up to 8 devices at one single poll) Standard industry libraries with Keysight IO Libraries Suite
SENSEPEEK - 6028 - Unleash the full measurement potential of your SQ oscilloscope probe from Sensepeek.Non destructive and non intrusive way to enable measurements over any SMD component in your signal or power path at your probes full rated bandwidth without any soldering.Perfect for measuring timing critical digital communication or ripple from your switch regulator or similar. And the best thing, it works handsfree!Includes:- 5× Ground spring needle 3.5 mmCompatible with the following Sensepeek probes: SQ200 SQ350 SQ500
